Overview

SYSTEM: GRAVITY UP / DOWN TILT DECK
1 - 3" X 16" CYLINDER
TANK- LARGE RESERVOIR
VALVE- 3 WAY VALVE CONTROL

8" I-BEAM (13 LBS/FT)
NECKBOSS 10" ENGINEERED I-BEAM
MEGA LOCKABLE TOOLBOX
ROBUST TOOLBOX LATCH
WELD ON SPARE TIRE MOUNT
OUTER DECK FRAME 3/16" DIAMOND PLATE

2 D-RINGS IN BETWEEN FENDERS
2" X 5" X 7GA. TUBING BED FRAME (TILT)
83" WIDE IN BETWEEN FENDERS
STORAGE BOX BEHIND NECK / WINCH READY
REMOVABLE FENDERS

HEIGHT- 70" HIGH (FROM UNDERNEATH NECK)
WELD ON SPARE TIRE MOUNT
STORAGE BEHIND NECK
STANDARD COUPLER
FRONT JACK
TOOLBOX
SAFETY CHAINS
STORAGE BOX / WINCH READY
ADJUSTABLE AUTO LATCH 2,5/16" BP COUPLER (17,000 LBS)
1 SIDE WIND SPRING LOADED DROP JACK LEG (12,000 LBS)
MEGA LOCKABLE TOOLBOX
3/B" GRADE 70 SAFETY CHAIN W/CLEVIS HOOK (2 EACH)

PINE LUMBER FLOOR
3" CHANNEL (3.50 LBS/FT) 16" SPACING
DECK WIDTH- 83”
WIDTH BETWEEN FENDERS- 83"
WELD ON D-RINGS
2 - D-RINGS IN BETWEEN FENDERS
BOLT ON SWIVEL D-RINGS
2 - FLUSH MOUNT GALVANIZED SWIVEL D-RINGS
SLOTS FOR LATCH ON TIE DOWN FITTINGS FRONT END OF DECK

16" BLACK MOD WHEELS
7K ELECTRIC BRAKE AUTO ADJUST OIL BATH TORSION AXLES
BOLT PATTERN- 8 ON 6.5"

BRIGHTWAY GROUP ELECTRIC BREAKAWAY KIT
ALL-WEATHER WIRING HARNESS (7-WAY RV)
DOUBLE INSULATED WIRING HARNESS
DOT APPROVED TECNIQ LED LIGHTS
3M DOT COMPLIANT REFLECTIVE TAPE
